The world’s most efficient commercial-grade digital signage media player for any type of business. Its power to display dynamic content on the screen will pull-in more customers and increase the potential of your business in no time!

Key Features

Powerful Graphics

Display gorgeous multimedia with video playback capable of 720p, 1080p, and 4K2K native and 8K upscaled display.

Reliable Operations

Never fear your digital signage going down due to WiFi or internet outages with both internal and expandable external storage as well as internet free operations.

Durable Design

A resilient aluminum die-cast casing and a fanless heat sink makes the Nano-PC3 resilient and able to operate in temperatures from -40°C - 103°C.

Adaptable Functionality

Nano-PC3's convenient form factor, orientation adapters , and audio/video interfaces make it able to function in any operating environment thrown at it.

Nano-PC 3 Setup

See how NexSigns stands out

Technical Specifications

  • Processor Type: Quad Core ARM Processor
  • Processor Speed: 1.5 GHz/Core
  • GPU: ARM Mali-450 / OpenGL ES 2.0
  • Memory: 2 GB
  • Storage: 4.8 GB (Internal) / Expandable via MicroSD (External)
  • Communication: Bluetooth, Bluetooth LE, Wi-Fi 2.4 GHz / 5 GHz
  • Built-In Video Decoder: H.264, H.265, AVI, RM/RMVB, WMV, MPEG-1, MPEG-2, HLS, RTMP
  • Built-In Audio Decoder: WAV, MP3, AAC, WMA, APE, FLAC, AAC, OGG, AC3
  • Output Resolution: 720p, 1080p, 4K2K, 8K (Upscaled)
  • Audio Output: HDMI
  • Power Input: 5V 2A
  • Operating System: Kuusoft NanoPC IoT 2019
  • Heat Sink Technology: Fan-less Heat Sink (Aluminum Die-Casting)
  • Warranty: 1 Year
  • Operating Temperature: -40°C – 103°C
  • Dimensions: 3.7cm x 12.1cm x 1.3cm
  • Weight: 70g

Contact Us Today to Learn More

Off to a Great Start

Our team will be able to provide you with advice and work with you to get your project started – for free.

Ideas and Planning

Based on your business needs, our team will assist you with identifying your objectives, determining your goals, and providing advice on your project budgets.

We’re here to help

Get professional advice from our highly trained NexSigns digital signage specialists for free at 1-866-546-8838.
