Ultrasonic Welding
Ultrasonic Welding seals the casing without a single screw, resulting in the Nano-PC 4’s protection from dust, grease, and other particles. This welding technique prevents air exchange with the external environment reducing the likelihood of circuitry oxidation enabling a long-lasting Nano-PC 4 with no down-time.
Industrial-Grade Casing
Using industrial-grade aluminum alloy die-casting, the Nano-PC 4 offers resilience against the demands of any environment, providing reliability you can trust.
Advanced Thermodynamics
The Nano-PC 4 features industry-first innovative dual heat sink with multi-fin design that provides advanced passive cooling without the use of active fans. Compared to its predecessor, the Nano-PC 4 features 2.5x more fins, resulting in a significant increase in the surface area to efficiently remove heat, allowing both the CPU and GPU to maintain high-frequency performance without any compromise.
Unyielding in Extreme Temperatures
Whether it’s in freezing -35 °C (-31°F) temperatures or scorching hot 70 °C (158 °F) inside a display enclosure, the Nano-PC 4 will not fail. The industrial-grade quality of all the components makes this device withstand any harsh environment it’s in.
EMI Shield
The Nano-PC 4 is the world’s first media player with an Electromagnetic Interference (EMI) Shield, raising the benchmark for reliability and stability of the digital signage industry. The EMI Shield also improves Nano-PC 4’s receptions of wireless communications by reducing the interference from external environment and internal circuitry.
Circular Antenna
The revolutionary circular antenna design of the Nano-PC 4 offers unparalleled signal reception, elevating the Wi-Fi and Bluetooth connectivity. This circular shape maximizes signal capture, ensuring the best possible connection quality even in a challenging environment.
Stay Connected
The Nano-PC 4 features dual-band Wi-Fi, enabling it to support multiple different frequencies for seamless operation even in highly congested environments or over long ranges.
Ultra-Flexible HDMI
With the Nano-PC 4, there’s no need for a separate HDMI cable for your media player. The fully integrated HDMI cable is designed with perfect length and flexible material to discreetly hide behind any display, making the setup hassle-free.
Fast & Reliable Storage
Equipped with a built-in Solid-State Drive (SSD) for internal storage, the Nano-PC 4 provides outstanding I/O speed resulting in fast loading times and effortless content updates to deliver your marketing messaging effectively and efficiently.
Powerful Multi-Tasking Performance
The Nano-PC 4’s architecture consists of multi-cores CPU and GPU providing unparalleled multi-tasking capabilities. Nano-PC 4 will tackle any task without skipping a beat and deliver remarkable digital signage experience.
Curious about the Nano-PC 4?
Hardware Decoder
At the heart of Nano-PC 4 lies a hardware decoder that provides zero-latency decoding for both video and audio, ensuring that your visual content is displayed on your screen with audio fully synced.
Video
The video-viewing experience has never been smoother. With this wide range of supported codecs, H.264, H.265, HEVC, and more. The Nano-PC 4 can effortlessly handle any modern video format.
Audio
Discover immersive audio with the refined audio decoder that delivers exceptional sound quality. Supporting industry-standard formats, such as WAV, MP3, AC-3, FLAC, and more, it elevates the listening experience to new heights.
4K Native Resolution
At the core of the Nano-PC 4 lies the powerful GPU that delivers breathtaking 4K resolution with absolute ease. Say goodbye to blurry content and unleash its full potential, where every visual bursts with life and detail.
Versatile Capabilities
Experience multi-peripheral expansion options with the Nano-PC 4, featuring an industry-standard USB-C for compatibility with wide-range of accessories to fulfill any unique business need.
Energy Efficient
Thanks to the Nano-PC 4’s custom System-on-a-Chip (SoC) running on ARM architecture, as well as custom silicon and advanced Power Management System, the Nano-PC 4 only uses 1% of electrical power compared to a typical PC media player without comprise in performance for digital signage applications.
Environmentally Responsible
Experience powerful performance while minimizing your Carbon footprint. The Nano-PC 4’s low power consumption not only reduces your electrical costs but also contributes to a sustainable future by reducing energy use and mitigating environmental concerns. For each device acquired, a tree is planted, helping you to make a positive impact on our planet.
Easy Setup
The Nano-PC 4 comes pre-configured and requires no additional accessories or extra steps—just plug it into your TV and start your digital signage within seconds.
The surrounding decorations are purely for aesthetics; the box includes only the Nano-PC 4 and its accessories.
What's in The Box
Nano-PC 4
USB-C Power Cable
USB-C Adapter
AC Power Adapter
Technical Specifications
- Processor Type: Quad Core ARM Cortex-A55 Processor
- Processor Speed: 1.9 GHz/Core
- GPU: ARM G31 MP2 GPU / OpenGL ES 3.2 / Vulkan 1.2 / OpenCL 2.0
- Memory: 4 GB
- Storage: 16 GB (Internal) / Expandable up to 4TB via USB-C
- Communication: Bluetooth 5.0, Wi-Fi 2.4 GHz / 5 GHz
- Built-In Video Decoder: H.264, H.265, AVI, VP9, RM/RMVB, WMV, MPEG-1, MPEG-2, MPEG-4, AVS-P16, VC-1, MJPEG, HLS, RTMP, RTSP
- Built-In Audio Decoder: WAV, MP3, AC3, AAC, WMA, RA, APE, FLAC, OGG
- Output Resolution: 720p, 1080p, 4K2K, 8K (Upscaled)
- Display Output: HDMI 2.1 with 3D ready + Dynamic HDR / HDCP2.2/2.3
- Interface: USB-C, Micro-USB, HDMI
- Power Input: 5V 2A
- Operating System: Kuusoft NanoPC IoT 2024
- Heat Sink Technology: Fan-less Heat Sink (Aluminum Die-Casting)
- Warranty: 1 Year
- Operating Temperature: –35°C-70°C (-31°F to 158 °F)
- Weight: 116g (0.25 lbs)
Legend of Nano-PC
The Nano-PC is more than just a product, it’s a device that sets a standard of quality that you can trust. Born from years of innovation, refinement, and dedication, uniquely designed for digital signage, the Nano-PC ensures that you receive nothing but the best. Each generation of the Nano-PC is Kuusoft’s commitment to breaking down technological barriers and providing you with the most reliable and efficient way to display your content.
